Abstract

Many papers discuss the voltage stability assessment of power system using power flow analysis methods. In this paper, a method for online monitoring of a power system based on measurements is proposed, which is aimed at detection of the voltage instability. Thereby an indicator is derived from the fundamental Kirchoff-Laws. Since in the transient process, at any time point, the electric power of the system is in balance, and the Kirchoff-Law is obeyed, this indicator will still work during the transient process. From the indicator, it is allowed to predict the voltage instability or the proximity of a collapse. The advantage of the method lies in the simple numerical calculation and strong adaptation in steady state and transient process. Through the indicator of voltage stability, it is easy to find the most vulnerable area in a system, to find the impacts of other loads, areas and power transactions.

Many papers discuss the voltage stability assessment of power system using power flow analysis methods. In this paper, a method for online monitoring of a power system based on measurements is proposed, which is aimed at detection of the voltage instability. Thereby an indicator is derived from the fundamental Kirchoff-Laws. Since in the transient process, at any time point, the electric power of the system is in balance, and the Kirchoff-Law is obeyed, this indicator will still work during the transient process. From the indicator, it is allowed to predict the voltage instability or the proximity of a collapse. The advantage of the method lies in the simple numerical calculation and strong adaptation in steady state and transient process. Through the indicator of voltage stability, it is easy to find the most vulnerable area in a system, to find the impacts of other loads, areas and power transactions.

**Keywords**: Voltage Stability, Voltage Collapse, Reactive Power, Steady-State Voltage Stability, Transient Analysis

Voltage stability is a major concern in planning and operations of power systems. It is well known that voltage instability and collapse have led to major system failures;with the development of power markets, more and more electric utilities are facing voltage stability-imposed limits.The problem of voltage stability may be simply explained as inability of the power system to provide the reactive power or the egregious consumption of the reactive power by the system itself. It is understood as a reactive power problem and is also a dynamic phenomenon. [8,9] The objective of this paper is to develop a fast and simple method, which can be applied in the power system online, to estimate the voltage stability margin of the power system. In general, the analysis of voltage stability problem of a given power system should cover the examination of these aspects:

- How close is the system to voltage instability or collapse?
- When does the voltage instability occur?
- Where are the vulnerable spots of the system?
- What are the key contributing factors?
- What areas are involved?

Voltage stability analysis often requires examination of lots of system states and many contingency scenarios. For this reason, the approach based on steady state analysis is more feasible, and it can also provide insights of the voltage reactive power problems. A number of special algorithms have been proposed in the literature for voltage stability analysis using static approached [2-4], however these approaches are laborious and does not provide sensitivity information useful in a dynamic process. Voltage stability is indeed a dynamic phenomenon. [8,9] Some utilities use Q-V curves at some load buses to determine the proximity to voltage instability [6]. One problem with Q-V curve method is that by focusing on a small number buses, the system-wide voltage stability problem will not be readily unveiled. An approaches, model analysis of the modified load flow Jacobian matrix, has been used as static voltage stability index to determine vulnerable bus’s voltage stability problem [7].

This paper explores the online monitoring index of the voltage stability, which is derived from the basic static power flow and Kirchoff law. A derivation will be given. The index of the voltage stability [3] predicts the voltage problem of the system with sufficient accuracy. This voltage stability index can work well in the static state as well as during dynamic process. It can also be used to find the vulnerable spots of the system, the stability margin based on the collapse point, and the key factors for the voltage stability problem, etc

Figure 1 · Single Generator and Load System

A simple power system is considered, through which the useful index of the voltage stability is derived. As showed in Fig.1, whereby bus 1 is assumed as a generator bus, and bus 2 is a load bus whose voltage behavior will be our interest.

This simple system can be described by the following equations (where the dot above a letter represents a vector):

Thereby an indicator has been derived which can be used for monitoring the voltage stability problem of the system and for assessing the degree of risk for a potential voltage collapse. When 0 2 *S* = , the indicator will be zero YL Load V2,I2,S2 YS G,V1 and indicates that there will be no voltage problem. When *S*2 = 1 , the voltage at load bus will collapse. One example of a single generator and load system was constructed to demonstrate the correctness of the indicator

Continuously change the load at bus 2, and keep the power factor of the load to find the collapse point

As shown in the basic theory of the multi-bus power system, all the buses can be divided into two categories: Generator bus (PV bus and Slack bus) and Load bus (PQ bus). Because the voltage stability problem is reactive power relative problem, and the generator bus can provide the reactive power to support the voltage magnitude of the bus, it is absolutely necessary that the all of buses be distinguished. The power system can be expressed in the form through Kirchoff Law:

Hence, we see that the voltage of the load bus j is affected by an equivalent complex power and by an equivalent generator part .

To compare the equation (17) and (2), we can observe that they have an identical form, and the voltage stability of the multi-bus system has been equivalent to a simple single generator and load system. The indicator of the voltage stability of the load bus j will be easily obtained:

Thereby it is clear that the indicator of the voltage stability at a load bus mainly influenced by the equivalent load ¢*j S* , which has two parts: the load at bus j itself, and the ‘contributions’ of the other load buses (showed at equation 20). When the load at a load bus changes, it will influence the indicator. On the other words, the voltage stability problem is a system-wide problem, not a local problem.Through equation (20), the contribution of any other load bus on the load bus j can be numerically updated and computed. It is a very important concept for the deregulated power market, and will help the customers and ISO to evaluate the responsibility of voltage stability problem.

The indicator is an effective quantitative measurement for the system to find how far is the current state of the system to the voltage collapse point. All the derivations are correct as long as that all the generator bus of the system have the enough reactive power supply to maintain the magnitude of voltage as constant. If some of the generators are unable to maintain the voltage magnitude, these generator buses will become load buses, the load bus congregation will expand; the indicator will have a discrete jump, which will be shown at the following demonstration.

Figure 2 · The IEEE 9 Bus Systems

The WSCC 9 bus system is taken as a sample system to illustrate the applicability of the indicator L to a multi-bus system. The test system is shown in Figure 2

Fig 2 Case scenarios of the test system:

- The normal base loading at load buses are:
- Bus 5: 90 + j 30 MVA
- Bus 7: 100 + j 35 MVA
- Bus 9: 125 + j 50 MVA

Buses 1 to 3 are generation buses; there are no generators or loads at buses 4, 6 and 8. Three case scenarios have been simulated to study the steady state voltage collapse at the load buses and their respective L index.

**Case I:**- Increase loading of bus 5 from zero to the voltage collapse point, keeping the load at other buses fixed at the normal value. Observe the effect on index L (5).
- Observe the effect on index L (7) at bus 7 when load at bus 5 is increasing and approaching collapse.
- Observe the effect on index L (9) at a bus 9, when load at bus 5 is increasing and approaching collapse.

**Case II:**- Increase loading of bus 7 from zero to the voltage collapse point keeping the load at other buses fixed at the normal value.
**Case III:**- Increase loading of bus 9 from zero to the voltage collapse point keeping the load at other buses fixed at the normal value.
*(Note: Power factor is kept constant throughout the loading of buses.)* **Case IV:**- Increasing load at bus 5 and observing the index (L) for bus 5, 7 and bus 9 and identify the first collapse point.
**Case V:**- Increasing load at bus 7 and observing the index (L) for bus 5, 7 and bus 9 and identify the first collapse point.
**Case VI:**- Increasing load at bus 9 and de serving the index (L) for bus 5, 7 and bus 9 and identify the first collapse point.

Increasing load at bus 5 and observing the indicator L at bus 5.

As shown in graph index L approaches one at the collapse point. For this simulation, the load at bus 7 is taken as 100+j35 MVA and the load at bus 9 is taken to be 125+j50 MVA.

The collapse occurs when the load at bus 5 is about 350+j115.5FIG 2.1: indicator for bus 5 with increased loading at bus 5P5(M.W) 0 100 200 250 300 375 V5(p.u) 1.014 0.971 0.909 0.867 0.809 0.635 L55 0.1662 0.2439 0.3177 0.3802 0.5171 0.8959 Increasing load at bus 5 and observing the indicator L at bus 7.

As shown in graph the voltage collapse point would not identified with index of L7 for the increasing of load at bus 5. For this simulation, load at Bus 5 is varied, the load at bus 7 is taken as 100+j35 MVA and the load at bus 9 is taken to be 125+j50 MVAFIG 2.2: indicator for bus 7 with increased loading at bus 5Table 2.2 · Data for variation of load at bus5 and for voltage at bus5 and for indicator L (7) P5(M.W) 0 100 200 300 350 375 V5(p.u) 1.014 0.971 0.909 0.809 0.707 0.635 L75 0.1124 0.1665 0.2305 0.3171 0.3941 0.4541 Increasing load at bus 5 and observing the indicator L at bus 9.

As shown in graph index L approaches one at the collapse point. For this simulation, the load at bus 7 is taken as 100+j35 MVA and the load at bus 9 is taken to be 125+j50 MVA.

The collapse occurs when the load at bus 5 is about 375+j123.75FIG 2.3: indicator for bus 9 with increased loading at bus 5Table 2.3 · Data for variation of load at bus 5 and for voltage at bus 5 and for indicator L (9) P5(M.W) 0 100 200 300 350 375 V5(p.u) 1.014 0.971 0.909 0.809 0.707 0.635 L95 0.1532 0.2262 0.3144 0.4392 0.5567 0.6519

Increasing load at bus 7 and observing the indicator L at bus 5.

As shown in graph index L approaches one at the collapse point. For this simulation, the load at bus 5 is taken as 90+j30 MVA and the load at bus 9 is taken to be 125+j50 MVA.

The collapse occurs when the load at bus 7 is about 425+j148.75FIG 2.4: indicator for bus 5 with increased loading at bus 7Table 2.4 · Data for variation of load at bus 7 and for voltage at bus 7 and for indicator L (5) P7(M.W) 0 100 200 400 450 V7(p.u) 1.014 0.986 0.944 0.775 0.723 L57 0.1627 0.2357 0.3215 0.6129 0.9976 Increasing load at bus 7 and observing the indicator L at bus 7.

As shown in graph index L approaches one at the collapse point. For this simulation, the load at bus5 is taken as 90+j30 MVA and the load at bus9 is taken to be 125+j50 MVA.

The collapse occurs when the load at bus 7 is about 435+j152.25FIG 2.5: indicator for bus 7 with increased loading at bus 7Table 2.5 · Data for variation of load at bus 7 and for voltage at bus 7 and for indicator L (7) P7(M.W) 0 100 200 300 450 V7(p.u) 1.014 0.986 0.944 0.833 0.723 L77 0.1127 0.1608 0.2216 0.3045 0.5356 Increasing load at bus 7 and observing the indicator L at bus 9.

As shown in graph index L approaches one at the collapse point. For this simulation, the load at bus 5 is taken as 90+j30 MVA and the load at bus 9 is taken to be 125+j50 MVA.

The collapse occurs when the load at bus 7 is about 425+J148.75FIG 2.6: indicator for bus 9 with increased loading at bus 7Table 2.6 · Data for variation of load at bus 7 and for voltage at bus 7 and for indicator L (9) P7(M.W) 0 100 200 300 450 V7(p.u) 1.014 0.986 0.944 0.833 0.723 L97 0.1508 0.2185 0.2983 0.4009 0.6572

Increasing load at bus 9 and observing the indicator L at bus 9.

As shown in graph index L approaches one at the collapse point. For this simulation, the load at bus5 is taken as 90+j30 MVA and the load at bus7 is taken to be 100+j35 MVA.

The collapse occurs when the load at bus9 is about 367.8+j147.12FIG 2.7: indicator for bus 9 with increased loading at bus 9Table 2.7 · Data for variation of load at bus 9 and for voltage at bus 9 and for indicator L (9) P9(M.W) 0 100 200 300 375 V9(p.u) 1.001 0.970 0.929 0.849 0.663 L99 0.1265 0.1982 0.2644 0.4343 0.7305 Increasing load at bus 9 and observing the indicator L at bus 5.

As shown in graph index L approaches one at the collapse point. For this simulation, the load at bus 5 is taken as 90+j30 MVA and the load at bus 7 is taken to be 100+j35 MVA.

The collapse occurs when the load at bus 9 is about 379.6+151.84FIG 2.8: indicator for bus 5 with increased loading at bus 9Table 2.8 · Data for variation of load at bus 9 and for voltage at bus 9 and for indicator L (5) P9(M.W) 0 100 200 300 377 V9(p.u) 1.001 0.970 0.929 0.849 0.663 L59 0.1352 0.2142 0.3070 0.4338 0.7302 Increasing load at bus 9 and observing the indicator L at bus 7.

As shown in graph the voltage collapse point would not identified with index of L7 for the increasing of load at bus 9. For this simulation, load at Bus 5 is varied, the load at bus 5 is taken as 90+j30MVA and the load at bus 7 is taken to be 100+j35 MVAFIG 2.9: indicator for bus 7 with increased loading at bus 9Table 2.9 · Data for variation of load at bus 9 and for voltage at bus 9 and for indicator L (7) P9(M.W) 0 100 200 300 375 V9(p.u) 1.001 0.970 0.929 0.849 0.663 L79 .0926 0.1461 0.2094 0.2929 0.4178

A real time measurement based voltage stability indicator for monitoring of the power systems is presented. We verify our approach by both static and dynamic simulations. We conclude that

- The indicator can predict the voltage stability problem correctly and properly by using both steady-state data as well as dynamic data
- The indicator can be used for both static and dynamic voltage problems
- Through the indicator, it is very easy to locate the vulnerable locations of the system
- The indicator can correctly predict the collapse point of the system.
- In the transaction based power system operation, through the indicator, it is easy to find the responsibility and obligation of the every customer and power supplier.
- The indicator has simple structure and can be handled easily.

The needed information can be obtained through local measurements and data exchanges of among preset buses.

- Detection of Dynamic Voltage Collapse By Gang. M. Huang
*, Senior Member, IEEE,*and Nirmal-Kumar C Nair*, Student Member, IEEE.* - Understanding and Solving Short-Term Voltage Stability Problems By John A. Diaz de Leon II,
*Member, IEEE*, and Carson W. Taylor,*Fellow, IEEE.*In Proceedings of IEEE/PES 2002 Summer Meeting. Invited paper for panel session on Power System Stability Controls Using Power Electronic Devices. © IEEE. - Investigating the Impact of Power former on Voltage Stability by Dynamic Simulation By Craig Anthony Aumuller
*, Member, IEEE,*and Tapan Kumar Saha*, Senior Member, IEEE.*IEEE TRANSACTIONS ON POWER SYSTEMS, VOL. 18, NO. 3, AUGUST 2003. - Voltage Security Assessment By Garng M. Huang, Professor Electrical Engineering Department,Texas A&M University and Garng M. Huang , Ali Abur Texas A&M University.
- Measurement based Voltage Stability Monitoring of Power system By Garng M. Huang , Liang Zhao.Department of Electrical Engineering. Texas A & M University College Station.
- Contribution Allocation for Voltage Stability In Deregulated Power Systems By Garng M. Huang,
*Senior Member, IEEE*, KunMen

***
